DONUT – Rescue

The AirDesign DONUT rescue system combines the positive characteristics from both square and annular (round) rescues. The DONUT is cut like a square canopy, but in the air presents more like that of a traditional annular. Subsequently, packing is still as simple as with conventional round rescue systems.

DONUT – square canopy in disguise!

The DONUT rescue system combines the positive characteristics from both square and annular (round) rescues.

In many drop-tests, we simulated real-life flight behaviour. The DONUT maintains its demonstrated safe and stable characteristics, even after repetitive tests and water landings.

Safety

The DONUT’s revolutionary design provides fast opening times.

Its four centre lines create a higher projected surface, resulting in low sink values. Side vents make the rescue impressively oscillation stable.

You may have noticed that we have elected to certify our rescue systems utilizing the EN certification norm over that of the LTF system norm.

This is due the fact that the maximum allowable sink rate for the EN system is 5.5m/s and the LTF system allows 6.7m/s. Never happy with achieving a minimum standard, we strived for an even greater level of safety, with our rescues achieving a sink rate of just 4.6m/s.

Weight

Due to the new design concept, we were able to reduce the total amount of material utilised compared to a conventional round rescue, placing the DONUT in the standard light rescue weight range. The 100kg max coming in at a mere 1300g, and the 120kg max at 1600g.

Therefore, the DONUT is one of the lighter rescues on the market and also allows longer Hike & Fly tours.



Technical Data

SIZE90100120220
AREA FLAT (m ²)22,225,5532,5864
WEIGHT RESCUE (kg)0,861,31,62,3
CERTIFICATION EN/LTFEN/LTFEN/LTFEN/LTF
MAX. LOAD (kg)90100120220
SINKRATE MAX LOAD (m/s) 5,495,174,905,35





Downloads

Thumb

EP_167-2016_Test_Donut_100_updated_s

EP_168-2016_Test_Donut_120_updated_s

EP_257-2019_Test_DonutSL_90

DONUT Handbuch - manual - manuel - DE-EN-FR - rev12

EP_167-2016_IC_Donut_100s_updated

EP_167-2016_ST_Donut_100

EP_168-2016_IC_Donut_120s_updated

EP_168-2016_ST_Donut_120

EP_257-2019_IC_DonutSL_90s

EP_257-2019_ST_DonutSL_90

Thumb

DONUT_web
